Premium Widebody Tri-Colour Prismatic Emergency Batten with Sensor Socket

oyster surface
SKU:
B2112PE / B2110PE
View Stockists

BATTEN

Premium Widebody Tri-Colour Prismatic Emergency Batten with Sensor Socket

Features

  • 20w/40w power selectable (4 foot only)
  • Fitted with a large terminal block allowing for fast installation and maintenance
  • Wide body to cover junction boxes and provides ample space for heat generating components
  • Tri-colour 3000k/4000k/5700k – switchable
  • Optional microwave sensor (MS02)
  • 1800mAh lithium battery technology
  • Designed and manufactured to AS/NZS2293

Dimensions

t8 premium emergency

Specifications

  2ft 4ft
Order Code B2112PE B2110PE
Model No LWBR2112PE LWBR2110-PE
Input Voltage 240v 240v
Wattage

20W
3.5W
(Emergency)

20W/40W
Switchable
3.5W
(Emergency)

Lumen Output 1000/2000lm 2000/4000lm
IP Rating IP20 IP20
Colour Temp Tri-colour (3000k, 4000k, 5700k) Tri-colour (3000k, 4000k, 5700k)
CRI >80 >80
Operation Mode Sustained Sustained
Operating
System
Manual Test Switch Manual Test Switch
Charging
Method
Intelligent current limited constant
voltage charge
Intelligent current limited constant
voltage charge

Battery

Lithium 1800mAh Lithium 1800mAh
Operating Temp. 1°C to 40°C 1°C to 40°C
AS 2293
Classification
C0=D63 C90=D32 C0=D63 C90=D32
Construction Powder coated steel Powder coated steel
Weight 2.1kg 4kg
Downloads


IES File
