JUPITER
IP54 Tri-Colour Oyster Light
Features
- Surface mounted oyster light
- High efficiency SMD chips
- Powder coated steel base
- Die-cast aluminium body
- Opal diffuser
- Large 6mm terminal block for easy installation
- Tri-colour 3000k/4000k/5700k - switchable
- Non-dimmable
- White/black finishes available
- Internal/external IP54 rating
Dimensions
Specifications
| 20W | 30W | |
| Order Code |
O4520W (White), O4520B (Black) |
O4530W (White), O4530B (Black) |
| Model No |
TLIU34520W (White), TLIU34520B (Black) |
TLIU34530W (White), TLIU34530B (Black) |
| Input Voltage | 240v | 240v |
| Wattage |
20W |
30W |
| Lumen Output | 1800lm | 2700ml |
| IP Rating | IP54 | IP54 |
|
Beam Angle |
120˚ | 120˚ |
| Diffuser | Opal | Opal |
| Colour Temp | Tri-colour 3000k/4000k/5700k | Tri-colour 3000k/4000k/5700k |
| Dimming Option | No | No |
| Terminal Block | 6mm | 6mm |
| Dimensions (mm) |
220x66 | 320x66 |
| Weight | 2.42kg | 3.1kg |
Downloads
