TEST SWITCH Emergency Lighting Test Switch Unit

SKU:
E-Test Switch
View Stockists

Test Switch

Emergency Lighting Test Switch Unit

Features

  • 4 pole enclosed emergency light test unit
  • Simulates supply failure in accordance with AS/NZS2293.2
  • Inbuilt timer
  • Rotary selector switch operation
  • Manual or automatic reset

Dimensions

Specifications

Order Code E-Test Switch
Model No CS-EMTK
Contactor 4 pole / 25A / NC / 230V
Operation Rotary selector switch operation
Time Delay Fully programmable
Operating Temp  5deg to 50deg
Rating IP20
Dimensions (mm) 160 x 122 x 85 mm
Cable Entry  4 sqmm

Downloads

Datasheet
