Highbay
LED 100/150/200W Tri-Colour Tri-Wattage
Features
- Light efficiency: 140lm/W-180lm/W
- Unique design, multiple power settings controlled by dip switch
- High bright SMD 2835, LM80 listed
- Optics of 120deg/90deg/60deg available on request
- High-transmittance and anti-UV polycarbonate lens
- Excellent thermal management design
- Die-cast aluminium with polyester powder coat finish
- IP65/IK08/4KV rating for outdoor usage
- Hook hanging and U-bracket installation are available
- Energy savings, no UV and IR radiations, emits low heat
- 0-10V or 1-10V dimming for low power consumption
- ETL/cETL/SAA/DLC/C-TICK/FCC/CE/RoHS approval
- 5 years warranty
Dimensions
Specifications
| Order Code | HB123-200 |
| Model No | TLHB123-200WTC |
| Input Voltage | 240v |
| Wattage |
100W/150W/250W |
| Lumen Output | 28,000lm,32000lm |
|
Beam Angle |
60deg/90deg/120deg |
|
Color Temp |
4000/5000/6500k |
| Fitting Colour |
Black |
| Dimensions (mm) |
400 x 151.7 |
| Weight | 2.7/6kg |
| Lifetime hours |
50,000 |
Downloads
